HMO系列浪涌選型參數表

所屬類別	型號名稱	主要參數說明
所屬類別	型號名稱	保護模式	Uc(V)	Imax(kA)	In(kA)	Up(kV)	Iimp(kA)	實驗類別
第1級（低風險）產品型號目錄
電源	HMO125-I /1P	/	385	/	/	1.8	25	T1
	HMO125-I /2P	L-PE/N-PE	385	/	/	1.8	25	T1
	HMO125-I /3P	L-PE	385	/	/	1.8	25	T1
	HMO125-I /4P	L-PE/N-PE	385	/	/	1.8	25	T1
	FNO125-I /1P	/	385	/	/	1.8	25	T1
	FNO125-I /2P	L-PE/N-PE	385	/	/	1.8	25	T1
	FNO125-I /3P	L-PE	385	/	/	1.8	25	T1
	FNO125-I /4P	L-PE/N-PE	385	/	/	1.8	25	T1
	HMO420/2P	L-PE/N-PE	385	20	10	1.4	/	T2
	HMO420/3P	L-PE	385	20	10	1.4	/	T2
	HMO420/4P	L-PE/N-PE	385	20	10	1.4	/	T2
	FNO420/2P	L-PE/N-PE	385	20	10	1.4	/	T2
	FNO420/3P	L-PE	385	20	10	1.4	/	T2
	FNO420/4P	L-PE/N-PE	385	20	10	1.4	/	T2
	HMO440/2P	L-PE/N-PE	385	40	20	1.5	/	T2
	HMO440/3P	L-PE	385	40	20	1.5	/	T2
	HMO440/4P	L-PE/N-PE	385	40	20	1.5	/	T2
	FNO440/2P	L-PE/N-PE	385	40	20	1.5	/	T2
	FNO440/3P	L-PE	385	40	20	1.5	/	T2
	FNO440/4P	L-PE/N-PE	385	40	20	1.5	/	T2
	HMO480/2P	L-PE/N-PE	385	80	40	2	/	T2
	FNO440/3P	L-PE	385	80	40	2	/	T2
	FNO440/4P	L-PE/N-PE	385	80	40	2	/	T2
	FNO480/2P	L-PE/N-PE	385	80	40	2	/	T2
	FNO480/3P	L-PE	385	80	40	2	/	T2
	FNO480/4P	L-PE/N-PE	385	80	40	2	/	T2
	HMO1100/1P	L/N-PE	385	120	60	2	/	T2
	FNO1100/1P	L/N-PE	385	120	60	2	/	T2
